Y8610U4001

Additional Information

Intermittent Pilot Retrofit Kits save energy by converting atmospheric standing pilot systems to intermittent pilot. Typical applications are gas-fired atmospheric furnaces, boilers and heating appliances.

Capacity

150,000 BTU/H

Dimension

3-15/16" H x 5-7/16" W x 2-5/8" D

Electrical Ratings (Vac)

24 Vac

Flame Failure Response Time (sec)

2.0 sec

Flame Sense

Single Rod or Two Rods

Frequency (Hz)

60

Ignition Sequence

Continuous retry, after trial for ignition, pilot gas shuts off for 5 minutes, then another trial for pilot ignition takes place

Ignition Source

Internal high voltage spark generator

Ignition System Type

Intermittent Pilot

Ignition Trial Time (Sec)

15 or 90 seconds

Ignition Trials To Lockout

continuous retry

Includes

S8610U3009 and VR8204A2142 with 1/2" by 1/2" inlet/outlet, Flange Kit, LP Conversion Kit

Item ID

1365000000

Lockout Timing (Sec)

15 or 90 seconds

Maximum Ambient Temperature (°F)

-40 °F to +165 °F

Maximum Valve Load @ 24 Vac (Amps)

1A Pilot, 2A Main @ 24Vac

Mfg #

Honeywell Home

PrePurge (Sec)

0 or 30 seconds

Product

Intermittent Pilot Retrofit Kit

Product Specific

Universal Intermittent Pilot Ignition Kit

Type of Gas

Natural or LP

Typical Gas Control

VR8204, VR8304

Unit of Measure

EA
