Mfg #: Honeywell Home
EIM RedLINK Equipment Interface Module with 2 Duct Sensors
| Location | Available |
|---|---|
| Signal Hill | 2 |
| Las Vegas | 2 |
| Tustin | 1 |
| Concord | 1 |
| San Bernardino | 0 |
| Pomona | 0 |
| Cathedral City | 1 |
| San Jose | 2 |
| El Cajon | 1 |
| Van Nuys | 1 |
| City of Industry | 1 |
| West Los Angeles | 1 |
| Los Angeles | 0 |
| Torrance | 1 |
| San Diego | 1 |
| San Leandro | 1 |
| Escondido | 2 |
Item ID
1365350000
Mfg #
Honeywell Home
Unit of Measure
EA
Application
Conventional or Heat Pump
Key Word
THM5421R1021
Product
Equipment Interface Module Kit
Type
Digital Programmable Thermostat
Additional Information
Equipment Interface Module controls up to 4-stages of heat and 2-stages of cool in a heat pump system and up to 3-stages of heat and 2-stages of cool in a conventional system. Three sets of Universal IAQ contacts to control humidification, dehumidificatio
Dimensions
9 5/16 in. High, 4 13/16 in. Wide, 1 5/8 in. Deep
Electrical
18 to 30 Vac
Color
Gray
Used With
All THX9421R5021 Prestige® 2-Wire IAQ Thermostats and all versions of Prestige® IAQ Thermostats and the VisionPRO® Thermostats with RedLINK technology.
Includes
THM5421R1021 Equipment Interface Module and 2 Duct Sensors
Mounting
Vertical
Frequency (Hz)
50/60
Electrical Connection
Screw terminals
Operating Humidity
-40 F to 165 F
Operating Humidity Range
5 to 95% RH, non-condensing
Power Source
Hardwired
Stages
4H/2C
Terminals
R, RC, RH, C, W-O/B, W2-AUX1, W3-AUX2, Y, Y2, G, A-L/A, U1, U1, U2, U2, U3, U3, S1, S1, S2, S2, S3, S3, S4, S4, A, B, C, D
Operating Ambient Temperature Range (F)
-40 F to 165 F
Power Method
Hardwired
