The image shown is an example. The actual item may vary.
WARNING: Cancer and Reproductive Harm - www.p65warnings.ca.gov
Mfg #: Tecumseh
1/3 HP, R-134A, 115-1-60, W/Stub Tube, Reciprocating Compressor
| Location | Available |
|---|---|
| Signal Hill | 205 |
| Las Vegas | 0 |
| Tustin | 31 |
| Concord | 5 |
| San Bernardino | 20 |
| Pomona | 7 |
| Cathedral City | 1 |
| San Jose | 16 |
| El Cajon | 15 |
| Van Nuys | 33 |
| City of Industry | 54 |
| West Los Angeles | 23 |
| Los Angeles | 36 |
| Torrance | 17 |
| San Diego | 6 |
| San Leandro | 12 |
| Escondido | 2 |
Item ID
2680205000
Mfg #
Tecumseh
Unit of Measure
EA
Application
HBP/CBP - High/Commercial Back Pressure
Bill of Material
Bill of Material AE1022E-212-J9 (UNBOXED)
HP
.33
Key Word
AEA4440YXA
Motor Torque
High
Oil Charge (oz)
9.5
Oil Type
Polyolester
Overload
K90-56
Product
Reciprocating Compressor
Rating Point
+45°F
Refrigerant
R-134A
Relay
K71-36
Release Variant
1st
Replaces
AEA4440YXA
Voltage
115-1-60
Weight (lbs)
22
Product Specific
AE2 Compressor
Motor Type
CSIR
Compressor Family
AE2
Condenser Temp (°F)
130°F
Discharge Line Size
1/4" ODF
Evaporating Temp Range (°F)
5°F to 59°F
Liquid Temperature (°F)
115°F
LRA
32
Oil Charge (cc)
285
Return Gas (°F)
95°F
RLA
5.82
Start Capacitor Mfd/Volt
K146-55, 324-389/165
Ambient Temperature (°F)
95°F
BTUH
4,350
Compressor Cooling
Fan
Displacement (cc)
10.33
Energy Efficiency Rating (Btu/Wh)
7.91
Motor Resistance (Ohm) - Main
1.65
Start Winding Resistance
3.44
Suction Line Size
5/16" ODF
Viscosity (cSt)
32
Voltage Range at 60 Hz
103.5 to 126.5
Max Continuous Current (Amp)
N/A
Displacement
N/A
Popular items frequently purchased together
Price unavailable
/EA
Price unavailable
/EA
Mfg #: Copeland Comfort Control
EK 032SVCAP (063208)
