Mfg #: Tecumseh
1 HP, R-404A/R-407A/R-448A/R-449A/R-452A, 208/230-1-60, Reciprocating Compressor
| Location | Available |
|---|---|
| Signal Hill | 5 |
| Las Vegas | 0 |
| Tustin | 0 |
| Concord | 0 |
| San Bernardino | 0 |
| Pomona | 0 |
| Cathedral City | 1 |
| San Jose | 0 |
| El Cajon | 0 |
| Van Nuys | 0 |
| City of Industry | 1 |
| West Los Angeles | 0 |
| Los Angeles | 0 |
| Torrance | 1 |
| San Diego | 0 |
| San Leandro | 0 |
| Escondido | 0 |
Item ID
2700592000
Mfg #
Tecumseh
Unit of Measure
EA
/images/items/AW Compressor.jpg
Application
CBP - Commercial Back Pressure
Bill of Material
Bill of Material AW619ET-172-J7
HP
1
Motor Torque
High
Oil Type
Polyolester
Overload
Internal
Product
Reciprocating Compressor
Rating Point
+20°F
Refrigerant
R-404A/R-407A/R-448A/R-449A/R-452A
Relay
K71-62
Release Variant
1st
Voltage
208/230-1-60
Weight (lbs)
70
Product Specific
AW Compressor
Motor Type
CSR
Compressor Family
AW
Condenser Temp (°F)
120°F
Discharge Line Size
3/8" ODF
Evaporating Temp Range (°F)
0°F to 50°F
Liquid Temperature (°F)
120°F
LRA
52
Oil Charge (cc)
1141
Return Gas (°F)
40°F
RLA
6.5
Start Capacitor Mfd/Volt
130-156/330
Ambient Temperature (°F)
95°F
BTUH
7,800 (R404A), X,XXX (R407A), 8,366 (R448), 8,366 (R449A), 7,565 (R452A)
Compressor Cooling
Fan
Displacement (cc)
30.547
Energy Efficiency Rating (Btu/Wh)
5.45 (R404A), X.XX (R407A), 6.20 (R448A), 6.20 (R449A), 5.58 (R452A)
Max Condensing Pressure Peak
16
Motor Resistance (Ohm) - Main
1.32
Motor Resistance (Ohm) - Main
2.72
Run Capacitor Mfd/Volt
25/370
Suction Line Size
1/2" ODF
Viscosity (cSt)
32
Voltage Range at 60 Hz
187-254
Max Continuous Current (Amp)
16
Motor Resistance (Ohm) - Start
2.72
