The image shown is an example. The actual item may vary.
WARNING: Cancer and Reproductive Harm - www.p65warnings.ca.gov
Mfg #: Tecumseh
1-3/4 HP, R-404A/R-407A/R-448A/R-449A/R-452A, 208/230-1-60, Reciprocating Compressor
| Location | Available |
|---|---|
| Signal Hill | 8 |
| Las Vegas | 0 |
| Tustin | 0 |
| Concord | 0 |
| San Bernardino | 0 |
| Pomona | 0 |
| Cathedral City | 0 |
| San Jose | 1 |
| El Cajon | 1 |
| Van Nuys | 0 |
| City of Industry | 1 |
| West Los Angeles | 0 |
| Los Angeles | 1 |
| Torrance | 0 |
| San Diego | 0 |
| San Leandro | 1 |
| Escondido | 0 |
Item ID
2700600000
Mfg #
Tecumseh
Unit of Measure
EA
/images/items/AW Compressor.jpg
Application
CBP - Commercial Back Pressure
Bill of Material
Bill of Material AW611FT-172-J7
HP
1.75
Motor Torque
High
Oil Type
Polyolester
Overload
Internal
Product
Reciprocating Compressor
Rating Point
+20°F
Refrigerant
R-404A/R-407A/R-448A/R-449A/R-452A
Relay
K71-19
Release Variant
1st
Voltage
208/230-1-60
Weight (lbs)
70
Product Specific
AW Compressor
Motor Type
CSR
Compressor Family
AW
Condenser Temp (°F)
120°F
Discharge Line Size
3/8"
Evaporating Temp Range (°F)
0°F to 50°F
Liquid Temperature (°F)
120°F
LRA
60
Oil Charge (cc)
1141
Return Gas (°F)
40°F
RLA
8.9
Start Capacitor Mfd/Volt
130-156/330
Ambient Temperature (°F)
95°F
BTUH
11,600 (R-404A), XX,XXX (R407A), 12,464 (R448), 12,464 (449A), 11,705 (R452A)
Compressor Cooling
Fan
Displacement (cc)
43.1
Energy Efficiency Rating (Btu/Wh)
5.71
Max Condensing Pressure Peak
19.4
Motor Resistance (Ohm) - Main
1.09
Motor Resistance (Ohm) - Main
2.53
Run Capacitor Mfd/Volt
35/370
Suction Line Size
5/8"
Viscosity (cSt)
32
Voltage Range at 60 Hz
187-254
Max Continuous Current (Amp)
19.4
Motor Resistance (Ohm) - Start
2.53
