Mfg #: Tecumseh
3 HP, Multi-Refrigerant, 208/230-3-60, Scroll Compressor
| Location | Available |
|---|---|
| Signal Hill | 3 |
| Las Vegas | 0 |
| Tustin | 0 |
| Concord | 0 |
| San Bernardino | 0 |
| Pomona | 0 |
| Cathedral City | 0 |
| San Jose | 0 |
| El Cajon | 0 |
| Van Nuys | 1 |
| City of Industry | 2 |
| West Los Angeles | 1 |
| Los Angeles | 1 |
| Torrance | 0 |
| San Diego | 0 |
| San Leandro | 0 |
| Escondido | 0 |
Item ID
2701020000
Mfg #
Tecumseh
Unit of Measure
EA
Application
LBP - Low Back Pressure
Bill of Material
Bill of Material VS2ZD1RC200J70 (Sweat)
HP
3
Motor Torque
High
Oil Type
Polyvinylether
Overload
N/A
Product
Scroll Compressor
Rating Point
-10°F
Refrigerant
MULTI REFRIGERANT
Relay
N/A
Release Variant
1st
Voltage
200/230-3-60
Weight (lbs)
N/A
Product Specific
VS Compressor
Motor Type
3PH
Compressor Family
VS
Condenser Temp (°F)
N/A
Discharge Line Size
N/A
Evaporating Temp Range (°F)
-40°F to 32°F
Liquid Temperature (°F)
N/A
LRA
136
Oil Charge (cc)
1600
Return Gas (°F)
N/A
RLA
13
Start Capacitor Mfd/Volt
N/A
Ambient Temperature (°F)
N/A
BTUH
N/A
Compressor Cooling
Fan
Displacement (cc)
58
Energy Efficiency Rating (Btu/Wh)
N/A
Motor Resistance (Ohm) - Main
N/A
Run Capacitor Mfd/Volt
N/A
Suction Line Size
N/A
Viscosity (cSt)
32
Voltage Range at 60 Hz
187-254
Max Continuous Current (Amp)
18
Motor Resistance (Ohm) - Start
N/A
