The image shown is an example. The actual item may vary.
WARNING: Cancer and Reproductive Harm - www.p65warnings.ca.gov
Mfg #: U.S. Motors
5 HP, 208-230/460 Volt, 3 Phase, 13.7-12.4/6.2 Amp, 1755/1440 RPM, ODP, 184T Frame Motor
| Location | Available |
|---|---|
| Signal Hill | 10 |
| Las Vegas | 1 |
| Tustin | 1 |
| Concord | 2 |
| San Bernardino | 1 |
| Pomona | 1 |
| Cathedral City | 0 |
| San Jose | 1 |
| El Cajon | 1 |
| Van Nuys | 1 |
| City of Industry | 1 |
| West Los Angeles | 1 |
| Los Angeles | 0 |
| Torrance | 1 |
| San Diego | 1 |
| San Leandro | 1 |
| Escondido | 1 |
Item ID
2901175000
Mfg #
U.S. Motors
Unit of Measure
EA
HP
5
Product
General Purpose Motor
Voltage
208-230/460
Motor Type
DE
RPM
1755
Shipping Weight
70
Mounting
Horz-Footed
Phase
3
Volts
460
Enclosure
Open
Model Number
FH82
Hertz
60
Speed
1
Insulation Class
F
Locked Rotor Torque
198
Service Factor
1.15
Ambient
40
Breakdown Torque UOM
PERCENT OF FLT
Full Load Amps Primary
13.7-12.4/6.2
Hertz 2
50
Kilowatts
3.7
Locked Rotor Amps
41
Locked Rotor Torque UOM
PERCENT OF FLT
Opposite End Bearing
6206-2Z-J/C3
Poles
4
Product Name
5 HP - ODP - 1755
Service Factor Amps Primary
15.9-14.1/7.1
Shaft Code
T
Shaft End Bearing
6206-2Z-J/C3
Volts 2
230
Volts 3
208
Assembly Position
F1
Breakdown Torque
305
Frame
184T
KVA Code Letter
H
Nema Nominal Efficiency
89.5
RPM 2
1755
RPM 3
1745
RPM 4
1440
Start Cap MFD
N/A
Volts 4
380
Volts 5
190
RPM 5
1440
