The image shown is an example. The actual item may vary.
WARNING: Cancer and Reproductive Harm - www.p65warnings.ca.gov
Mfg #: Embraco
1-1/2 HP, R-404A/R507, 208-230-60-1, Reciprocating Compressor
| Location | Available |
|---|---|
| Signal Hill | 19 |
| Las Vegas | 1 |
| Tustin | 1 |
| Concord | 1 |
| San Bernardino | 1 |
| Pomona | 0 |
| Cathedral City | 0 |
| San Jose | 2 |
| El Cajon | 1 |
| Van Nuys | 0 |
| City of Industry | 2 |
| West Los Angeles | 1 |
| Los Angeles | 1 |
| Torrance | 1 |
| San Diego | 0 |
| San Leandro | 1 |
| Escondido | 1 |
Item ID
2936920000
Mfg #
Embraco
Unit of Measure
EA
Application
LBP - Low Back Pressure
Bill of Material
Engineering Code 943ED1104AF
HP
1.5
Overload
Internal
Product
Reciprocating Compressor
Refrigerant
R404A/R507
Relay
RVA2L3C-112 (1253010)
Type
Hermetic reciprocating
Voltage
208/230-1-60
Weight (lbs)
47.2
Product Specific
NJ Compressor
Motor Type
CSCR
Discharge Line Size
5/16" ODF
Evaporating Temp Range (°F)
-40ºF to 14ºF
LRA
54 amps
RLA
9.2 amps
Start Capacitor Mfd/Volt
130-156/330 (2252274)
BTUH
6,067
Compressor Cooling
Fan/NotControled/208
Energy Efficiency Rating (Btu/Wh)
4.44
Fan Air Flow
48819224 in³/h
Free Internal Volume
0.9 gal
Max Condensing Pressure Peak
27.71 bar
Maximum Recommended Refrigerant Charge
2 Lb
Oil Charge
0.16 gal
Oil Type Configuration
ESTER
Pressurization
Dry air charge
Run Capacitor Mfd/Volt
20/440 (2253312)
Run Winding Resistance
1.05 Ohm at 77° F
Start Winding Resistance
4.18 Ohm at 77° F
Starting Torque
HST
Suction Line Size
1/2" ODF
Voltage Range at 60 Hz
187-244V
Displacement
34.38 cm³
Expansion Device
Capillary Tube or Expansion Valve
Max Condensing Pressure Operating
24.71 bar
Process Line Size
1/4" ODF
Technology Type
On-Off
